1. Khoom Taw Qhia
Kos npe
Cov khoom cim ntawmtawg vuamstainless hlau clad phajyog tsim los ntawm cladding steel tooj, lub hauv paus khoom steel tooj, qhov loj, qib code, tus qauv tooj, thiab lwm yam. Saib Daim Ntawv Ntxiv A rau qhov kwv yees sib piv ntawm cov lej sib koom ua ke ntawm cov hlau tsis muaj hlau thiab qib qub.
Piv txwv 1: S32168 phaj nrog 3 hli thickness cladding khoom, Q345R phaj nrog 16 hli thickness puag khoom, qib 2 composite phaj nrog 2500mm dav thiab 8000mm ntev yog cim raws li: (S32168 plus Q345R) - (3 plus 16) × 2500 × {{14} }}CLASS 3-ASTM A264
Piv txwv 2: S30408 phaj nrog 8mm thickness cladding, 16Mn qib III forging nrog 150mm thickness puag khoom, thiab qib 1 composite phaj nrog 4000mm txoj kab uas hla yog cim raws li (S30408 ntxiv 16Mn) - (8 ntxiv 150) × D4000-CLAS 1-ASTM A264
Piv txwv 3: S31603 phaj nrog 3mm thickness ntawm ib sab, Q345R phaj nrog 20mm thickness ntawm lub hauv paus, S30408 phaj nrog 2mm thickness ntawm sab nraud, thiab qib 2 composite phaj nrog 2000mm dav thiab 6000mm ntev yog cim raws li (S31603 ntxiv Q345R ntxiv S30408) - (3 plus 20 plus 2) × 2000 × 6000-CLASS 3-ASTM A264
Daim Ntawv Ntxiv A:
Qib | |
Unified tooj code | Qib qub |
S11306 | 0Cr13 |
S11348 | 0Cr13Al |
S11972 | 00Cr18Mo2 |
S3O4O8 | 0Cr18Ni9 |
S30403 | 00Cr19Ni10 |
S32168 | 0Cr18Ni10Ti |
S31603 | 00Cr17Ni14Mo2 |
S31668 | 0Cr18Ni12Mo2Ti |
S31703 | 00Cr19Ni13Mo3 |
S39042 | — |
S21953 | 00Cr18Ni5Mo3Si2 |
S22053 | 00Cr23Ni5Mo3N |
2. Mechanical zog
Kev xeem shear: Kev sib xyaw shear zog ntawm kev sib txuas ntawm cov phaj clad yuav tsum tsis pub tsawg dua 210Mpa. Rau ob-sided composite boards, txawv sab cladding cov ntaub ntawv yog tshwj tseg rau kev xeem shear.
Tensile xeem: Rau ob-sided composite phaj, tsuas yog ib hom ntawm cladding khoom yog tshwj tseg rau lub tensile xeem, thiab cov khoom cladding yuav tsum tau tshwj tseg yuav tsum tau qhia los ntawm buyer nyob rau hauv daim ntawv cog lus. Thaum lub thickness ntawm cov khoom siv hauv paus yog ntau dua 40mm los yog teev los ntawm tus neeg yuav khoom, tsuas yog kev sim tensile ntawm cov khoom siv hauv paus yuav tsum tau ua, thiab cov txiaj ntsig kev xeem yuav tsum ua raws li cov kev cai ntawm cov khoom siv hauv paus.
Tsuas yog qhov kev ntsuam xyuas cuam tshuam ntawm cov khoom siv hauv paus yuav tsum tau ua rau cov phaj sib xyaw, thiab qhov ntsuas qhov ntsuas kub thiab qhov cuam tshuam lub zog yuav tsum ua raws li cov kev cai ntawm cov khoom siv hauv paus. Yog tias tsis muaj qhov yuav tsum tau ua rau qhov kev ntsuam xyuas cuam tshuam hauv cov txheej txheem cov khoom siv, cov phaj sib xyaw yuav tsis raug rau qhov kev sim cuam tshuam.
3. Intergranular corrosion test
Raws li qhov yuav tsum tau muaj ntawm tus neeg yuav khoom thiab los ntawm kev pom zoo ntawm tus neeg muag khoom thiab tus neeg yuav khoom, tus neeg muag khoom tuaj yeem ua qhov kev ntsuam xyuas intergranular corrosion ntawm composite phaj cladding, thiab cov kev cai xeem thiab cov qauv tsim nyog yuav tsum tau pom zoo los ntawm tus neeg muag khoom thiab tus neeg yuav khoom.
4. Ntim, cim, thiab daim ntawv pov thawj zoo
Txhua daim phaj sib xyaw yuav tsum tau cim nrog cov khoom cim, batch tooj, chaw tsim khoom lub npe (lossis lub Hoobkas logo), hnub tsim khoom, thiab lwm yam.
Thaum xa cov phaj sib xyaw, cov khoom pov thawj zoo (thawj) ntawm cov phaj sib xyaw yuav tsum muab, thiab cov ntawv luam ntawm daim ntawv pov thawj zoo ntawm cov ntaub npog thiab cov khoom siv hauv paus yuav tsum muab rau tib lub sijhawm.
Qhov saum npoo ntawm cov phaj sib xyaw yuav tsum muaj kev tiv thaiv zoo kom tsis txhob khawb.
Lwm yam yuav tsum tau ua raws li ASTM A264.
5. Peb qhov zoo dua
Peb muaj qhov zoo tshaj plaws, ib puag ncig, thiab kev ruaj ntseg kev ruaj ntseg, peb tau ua tiav dhau ISO9001 cov ntawv pov thawj zoo thiab EU PED ntawv pov thawj, thiab peb cov khoom tau txais daim ntawv pov thawj tsim qauv ntawm Asmeskas kev faib tawm hauv zej zog. Lub "Taicheng Hexin" hom titanium / steel clad phaj tau raug lees paub tias yog cov khoom lag luam nto moo hauv Shaanxi Xeev los ntawm Pawg Neeg Ua Haujlwm Txhawb Kev Ua Haujlwm ntawm Shaanxi Xeev nrog muaj zog zoo. Peb tau txais 1 lub teb chaws invention patent thiab 17 cov qauv siv hluav taws xob patents, thiab tau lees paub tias yog lub tuam txhab high-tech los ntawm Shaanxi science thiab technology department.
Peb Taicheng Hlau tuaj yeem muab koj qhov siab tshaj plaws ntawm kev tawg vuam stainless hlau clad phaj yog 3000mm, qhov siab tshaj plaws ntev yog 1000mm, thiab qhov siab tshaj plaws cheeb tsam feem ntau tsis tshaj 20m2. Qhov siab tshaj plaws txoj kab uas hla ntawm lub voj voog sib xyaw phaj yog 4000mm. Raws li kev pom zoo ntawm tus neeg muag khoom thiab tus neeg yuav khoom,stainless hlau clad phajtshaj qhov saum toj no qhov ntev tuaj yeem muab tau.
